EcoTemp 80% Single Stage 135K BTU Gas Furnace, WFER135D060C
The WFER135D060C tops the EcoTemp WFER range: 132,000 BTUH of natural gas input, 107,000 BTUH of output at 80.00% AFUE, six monoport burners, and the widest cabinet in the series at 24-1/2 in. A 3/4 HP five-speed blower with an 11 x 11 in. wheel moves 1760 CFM in heating and 1810 CFM in cooling behind a 5 ton condenser. It is the only size in the family that needs a larger flue – a 5 or 6 in. vent with an adapter between the furnace and the vent stack – which is the first thing to check when specifying it as a replacement.
Is a 135K BTU Gas Furnace the Right Size?
At 107,000 BTUH delivered this is a large-home or cold-climate furnace: sprawling floor plans, houses with substantial envelope loss, additions on a single system, or northern installations where design temperature is well below freezing. The 060 cooling code puts a 5 ton blower behind it. Its certified temperature rise range is 40°F to 70°F, the highest band in the line, reflecting the heat six burners put into the airstream.
Sizing at this capacity deserves particular care. A 132,000 BTUH input furnace in a home that only needs 80,000 will short cycle badly, and the oversizing penalty compounds with an 80% single stage burner that has no low-fire mode to fall back on. Run the heat loss calculation. Then confirm three things before ordering: that the gas supply and meter can carry 132,000 BTUH, that the vent can be adapted to 5 or 6 in., and that the mechanical space will take a 24-1/2 in. cabinet and a 167 lb unit.
Ideal for: Large homes with high heat loss, cold-climate installations, older properties with weak envelopes, and 5 ton system matches with room for a 24-1/2 in. cabinet.
Already at the top? The 135K is the largest furnace in the WFER series – compare the rest of the range on the 80% metal-vented furnace page, or consider a 92%+ PVC-vented condensing furnace where higher efficiency is worth the venting change.
Recommended applications are general guidelines only. Actual furnace selection depends on a calculated heat loss, duct design, venting, gas supply and local code. Request free sizing assistance, contact Budget Heating, or call 813-885-7999.
What’s Included
| Model Number | WFER135D060C – 80% AFUE Single Stage Multipoise Gas Furnace |
|---|---|
| Heating Input | 132,000 BTUH (Natural Gas) |
| Heating Output | 107,000 BTUH |
| Efficiency | 80.00% AFUE |
| Cabinet Width | 24-1/2 in. |
| Cooling Size | Up to 5 Ton / 60,000 BTUH |
| Airflow | 1760 CFM Heating / 1810 CFM Cooling |
| Blower Motor | 3/4 HP Direct Drive, 5 Speed, 11 x 11 in. Wheel |
| Burners | 6 Monoport |
| Certified Temperature Rise | 40°F – 70°F |
| Installation Positions | Upflow, Downflow, Horizontal-Left, Horizontal-Right |
| Ignition | Hot Surface Ignition |
| Electrical / Gas Connection | 115V-60Hz-1Ph, 10.7 Max Amps / 1/2 in. NPT |
| Vent Connection | 5 in. or 6 in. Required (Vent Adapter Needed) |
| Shipping Weight | 167 lb |
| Warranty | 1-Year Unit Replacement, 20-Year Heat Exchanger, 5-Year Parts (10-Year with Registration) |
The venting requirement is the key planning item: the 135 size needs a 5 or 6 in. vent, using an adapter between the furnace and the vent stack – see the installation instructions and browse ventilation pipe and accessories. The 24-1/2 in. cabinet takes external bottom filter rack NAHB00801FF with a 24 x 25 in. washable filter. Pair the cooling side with a 5 ton coil such as the EcoTemp W5AM61M24XA R-454B cased coil, whose 24-1/2 in. casing matches this cabinet exactly.
Furnace & Blower Features
WFER135D060C Heating & Controls
- 132,000 BTUH input and 107,000 BTUH output at 80.00% AFUE
- Six monoport burners – the most in the WFER line
- Hot surface ignition with electronic control center
- LED diagnostics and self-test feature standard
- Certified temperature rise 40°F to 70°F
- WhiteRodgers redundant gas valve, 1/2 in. NPT connection
- Size 43 factory orifice; propane conversion via AGAGC8NPS01A
- Solid state time operation heating blower control
- 20-year heat exchanger limited warranty
- Standard NOx configuration, AHRI certified
WFER135D060C Cabinet & Airflow
- 24-1/2 in. cabinet, the widest in the WFER series
- 22-7/8 in. supply outlet, 23 in. bottom inlet width
- 15-1/16 in. top and bottom flue collar
- 3/4 HP five-speed direct drive blower, 11 x 11 in. wheel, 8.8 FLA
- 1760 CFM heating and 1810 CFM cooling as shipped
- Gray cooling tap reaches 2065 CFM at 0.1 in. w.c.
- Certified external static pressure 0.20 heating / 0.50 cooling
- Requires 5 or 6 in. vent with adapter to the vent stack
- 10.7 max amps, 14 ampacity, 15 amp maximum breaker
- 167 lb shipping weight – plan for two-person handling
Specifications & Manuals
The dimensions table footnote states that the 135 size requires a 5 or 6 in. vent with an adapter between furnace and vent stack. Review the downflow vent configuration diagrams and the vent guard kit requirement in the installation instructions before planning a downflow install.
